    PRODUCT & POWER OPTIONS

    Product Name Light Color Input Voltage (V) Power (W/mt) Luminous Flux (lm) Product Weight (kg)
    LLUT 30LED WW-NW-CW 24V DC 2,4 245 0,455
    LLUT 30LED WW-NW-CW 24V DC 4,8 485 0,455
    LLUT 45LED WW-NW-CW 24V DC 7,2 615 0,455
    LLUT 45LED WW-NW-CW 24V DC 10,8 1065 0,455
    LLUT 60LED WW-NW-CW 24V DC 7,2 715 0,455
    LLUT 90LED WW-NW-CW 24V DC 10,8 905 0,455
    LLUT 30LED RGB 24V DC 7,2 - 0,455
    LLUT 45LED RGB 24V DC 10,8 - 0,455
    LLUT 30LED-DMX RGB-Pixel 24V DC 8,4 - 0,455
    LLUT 45LED-DMX RGB-Pixel 24V DC 12,6 - 0,455

    *Power and Lumen values provided are based off of a “cold white (CW) LED”.

    ELECTROMECHANICAL SPECIFICATIONS

    • Min. 20 micron anodized aluminum extruded profile
    • Anodized aluminum housing
    • Rubber power cable
    • Stainless connectors
    • Insulated, PVC side cover
    • UV protective transparent tube
    • Cooling capacity up to 21,6 W/m
    • Suitable for surface mounting

  • C

    LIGHT COLOR OPTIONS

    WW:Warm White 3000K R:Red 625nm
    NW:Natural White 4000K G:Green 525nm
    CW:Cold White 6500K B:Blue 465nm
    RGB A:Amber 590nm
  • K

    CABLE DIRECTION OPTIONS

    • 01: Left side
    • 03: Left and Right Side
  • CONTROL SYSTEM OPTIONS

    Color Type PWM INW PWM DMX DALI 0 - 10V DC TRIAC
    WW-NW-CW
    R,G,B,A
    RGB
    RGBA/W
    RGB DMX
    WHITE DMX
  •  PRODUCT DIAGRAMS
    LLUT LLUT
  • a7.svg
  • a14.svg
  • c4.svg
  • c5.svg
  • c11.svg
  • c15.svg
  • c13.svg
  • b28.svg
  • b37.svg
