LEDLine / ERL100

PRODUCT & POWER OPTIONS

Product Name	Light Color	Input Voltage (V)	Power (W)	Luminous Flux (lm)	Product Weight (kg)
ERL100	WW-NW-CW	24V DC	24	1.440	2,3
ERL100	WW-NW-CW	24V DC	36	2.160	2,3
ERL100	WW-NW-CW	24V DC	48	2.880	2,3
ERL100	WW-NW-CW	24V DC	54	3.240	2,3
ERL100	WW-NW-CW	24V DC	72	4.320	2,3

*Power and Lumen values provided are based off of a “cold white (CW) LED”.

ELECTROMECHANICAL SPECIFICATIONS

• Min. 20 micron anodized aluminum extruded profile
• Stainless connectors
• ABS end caps with UV protection
• Diffused polycarbonate top cover with UV protection
• Cooling capacity up to 72 W/m
• Suitable for recessed mounting

C
LIGHT COLOR OPTIONS

WW:Warm White 3000K

NW:Natural White 4000K

CW:Cold White 6500K
K
CABLE DIRECTION OPTIONS
- 01: Single Entry
- 03: Dual end exit and entry
U
PRODUCT OPTIONS
- 05: Flat deep surface
- 06: Flat surface
- 07: Oval deep surface
- 08: Surface with oval finish

PRODUCT LENGTH OPTIONS FOR ERL 100 FLAT

Product Code	*Min. length (L) mm	**Application length	Power (W)	Outer Dimension (L1)
ERL100	220	200	24	L+14
ERL100	153	133	36	L+14
ERL100	120	100	48	L+14
ERL100	153	133	54	L+14
ERL100	86	66	72	L+14
ERL100	220	200	14	L+14
ERL100	120	100	28	L+14
ERL100	220	200	43	L+14

*"L" product length with end caps

**Application length formula( L) =min. length +( Application length x Qty )

PRODUCT LENGTH OPTIONS FOR ERL 100 OVAL

Product Code	*Min. length (L) mm	**Application length mm	Power (W)	Outer Dimension (L1)
ERL100	280	200	24	L+14
ERL100	213	133	36	L+14
ERL100	190	100	48	L+14
ERL100	213	133	54	L+14
ERL100	146	66	72	L+14
ERL100	280	200	14	L+14
ERL100	180	100	28	L+14
ERL100	280	200	43	L+14
